Nominal parameter

AC current output

The virtual value of each phase output when six phase current output  0～30A    output precision   0.2 grade

The virtual value of each phase output when three phase current output  0～60A

The virtual value of six phase parallel current output                    0～180A

The allowed virtual value when the phase current work long time        10A

The maximum output power of phase current                         450VA

The maximum output power when six phase parallel current output      1000VA

The allowed working time when six phase parallel current maximum output    10s

Frequency range（fundamental wave）                             0～1000Hz

Harmonic order                                                   0～20

DC current output

Current output            0～±10A / phase       output precision   0.2 grade

The maximum load volatage output                                 20V

AC voltage output

The virtual value of phase voltage output  0～120V    output precision  0.2grade

The virtual value of line voltage output                               0～240V

The output power of phase voltage/ line voltage                    80VA / 100VA

Frequency range（fundamental wave）                             0～1000Hz

Harmonic order                                                   0～20

DC voltage output

The output amplitude of phase voltage  0～±160V   output precision  0.2 grade

The output amplitude of line voltage                                0～±320V

The output power of phase voltage/ line voltage                     70VA / 140VA

Input and output

8 channels input

Free contact                                     1～20mA，24V

Electric potential contacts     “0”：0 ～ +6V； “1”：+11 V ～ +250 V

4 channels output                        DC：220 V／0.2 A；AC：220 V／0.5 A

Time measurment range

0.1ms ～ 9999s ，    measurement accuracy ＜0.1ms
