I. Main technical features

1.It adopts integral structure. Easy to use and good-looking.

2.The buzzer will sound after the completion of suction filtration of the instrument.

3. It adopts digital display technology, easy to set data, stop timing when the timing time arrives.

4. Equipped with SYD-510G, it can realize Cold Filter Plugging Point test.II.Main technical parameters

II. Main technical specifications

1. Power supply:  AC 220V±10%, 50 Hz

2. Pumping pressure:  1961 Pa (200mm±1mm)

3. Test cup:  There is a mark line at 45 ml of the cup.

4. Filter assembly:  It is made of cooper; Size of hole on the filter sieve is 45 μm (330 meshes)

5. Working environment:

Ambient temperature: (15～+35)℃

Relative humidity: ≤85%

6. Power consumption:  ≤150W

7. Dimension:  550mm×250mm×400mm
